Cooling Agent WS-5 | Long-Acting High-Impact Cooling
Cooling Agent WS-5 Product Overview
What Is Cooling Agent WS-5?
Cooling Agent WS-5 is a food-grade synthetic cooling agent. Its chemical name is N-((Ethoxycarbonyl)methyl)-p-menthane-3-carboxamide. It comes from the menthol family, yet it ranks among the strongest agents in the WS series.
First, WS-5 stays virtually odorless and tasteless. Therefore, it cools the mouth without adding any mint aroma or bitterness. Second, it activates the TRPM8 cold receptor on the tongue and the roof of the mouth. As a result, the cooling starts smoothly and holds for more than 30 minutes.
Third, WS-5 carries a long record of food use, and it holds FEMA number 4309. It also carries CAS number 68489-14-5. Consequently, formulators choose it whenever the cooling must outlast the product itself.
Cooling Agent WS-5 Technical Specifications
| Item | Specification |
| Product Name (EN) | Cooling Agent WS-5 |
| Chemical Name | N-((Ethoxycarbonyl)methyl)-p-menthane-3-carboxamide |
| Synonyms | WS-5; Ethyl 2-[[(1R,2S,5R)-5-methyl-2-propan-2-ylcyclohexanecarbonyl]amino]acetate |
| CAS Number | 68489-14-5 |
| FEMA Number | 4309 |
| JECFA Number | 1776 |
| Molecular Formula | C15H27NO3 |
| Molecular Weight | 269.38 g/mol |
| Appearance | White to off-white crystals / crystalline powder |
| Odor | Slight minty note; practically odorless |
| Taste | Smooth, well-rounded cooling without bitterness |
| Assay (Purity) | >= 99.0% (HPLC) |
| Melting Point | 80 – 82 °C |
| Flash Point | 190 °C |
| Solubility | Soluble in ethanol, propylene glycol and other food-grade solvents; practically insoluble in water (< 0.1%) |
| Cooling Duration | More than 30 minutes |
| Cooling Character | Smooth, well-rounded wave centered on the roof of the mouth and the back of the tongue |
| Recommended Dosage | Beverage 0.1-1 mg/kg; candy 1-20 mg/kg; chewing gum 15-300 mg/kg; toothpaste 50-400 mg/kg; mouthwash 5-100 mg/kg; cream and lotion 500-5000 mg/kg |
| Heat Stability | Stable up to 200 °C |
| Category | Cooling Agents |
| Storage Conditions | Store in a cool, dry place. Keep away from direct light and heat. Close the package tightly after use. |
| Shelf Life | 24 months when stored properly |
Cooling Agent WS-5 Applications & Uses
Confectionery & Chewing Gum Applications
Cooling Agent WS-5 delivers its long-acting coolness in:
- Chewing gum and bubble gum
- Pressed candy and table candy
- Hard candy and chewy candy
- Gummies and jelly
- Chocolate and compound coatings
- Mint and sugar-free confectionery
Beverage & Dairy Applications
The cooling agent also performs well in:
- Beer and distilled spirits
- Sparkling water and flavored soda
- Ready-to-drink beverages and iced tea
- Energy drinks and sports drinks
- Flavored milk and drinking yogurt
- Ice cream, sorbet and frozen dessert
- Syrups and cordials
Oral Care Applications
Oral care formulators commonly add WS-5 to:
- Toothpaste and whitening gel
- Mouthwash and breath freshener
- Dental gel and dental floss
- Breath strips and oral sprays
- Lozenges and throat drops
Personal Care, Tobacco & Pharmaceutical Applications
WS-5 also supports:
- Skin cream and body lotion
- Face mask and cooling gel
- Shaving cream and after-shave
- Shampoo and scalp care
- Sunscreen and after-sun lotion
- E-liquids and vape formulas
- Tobacco products and cigarette filter tips
- OTC liniments and cooling balms
- Cooling patches and plasters
- OEM flavor and cooling blends
Certifications & Compliance
We can provide the following quality and product documents:
- ISO 9001:2015 — Quality Management System
- ISO 22000 — Food Safety Management
- GMP — GMP-aligned manufacturing facility
- HALAL — Certified batches available
- KOSHER — Certification available upon request
- COA / MSDS / TDS — Product documents available for each lot
- FEMA 4309 / JECFA 1776 — Flavor industry listings
- Non-Restricted Cargo — Standard export classification
- Third-party laboratory testing — SGS, Eurofins or your selected laboratory
Packing & Logistics
Standard Package
Powder: 1 kg / aluminium-foil bag; 25 kg / fiber drum.
Liquid blend: 1 kg / bottle; 5 kg and 25 kg / drum.
Carton Dimensions
22 cm × 16 cm × 34 cm
Packaging Material
We pack the crystalline powder in food-grade aluminium-foil bags. We then place the bags inside strong cardboard cartons or HDPE-lined fiber drums. The liquid blend goes into food-grade HDPE bottles and drums.
Sealing
We seal each package with three layers of tape winding and shock-resistant packing.
Net Weight
1 kg per standard package.
Custom package sizes such as 5 kg and 25 kg are available upon request.
Need specifications, COA, or a wholesale quote? Contact Us — typical response within 24 hours.
